Page 11
CONTROLS & FEATURES
9
Flywheel Brake Lever
This lever is connected to the engine flywheel brake and the ignition
switch. The engine will not start unless this lever is pushed forward.
Drive Clutch Lever
The drive clutch lever engages and disengages the transmission that
drives the rear wheels.
FLYWHEEL BRAKE LEVER
DRIVE CLUTCH LEVER
FLYWHEEL BRAKE LEVER
