149004PM040702

GRASSBAG MOUNTING

1.19

1.19

1

Nut

AL700121

15

2

Guard

AL521195

1

3

Bolt

AL700967

2

4

Bolt

AL701672

1

5

Bracket

AL51475201

1

6

Bolt

AL701006

3

7

Bolt

AL701011

1

8

Nut

AL700276

2

9

Washer

AL700137

2

10

Clip - Plastic

AL317280

2

11

Star Washer

AL511249

1

12

Spring

AL521042

1

13

Box Clutch

AL51493630

1

14

Back Plate

AL51483801

1

15

Bolt

AL700702

2

16

Washer

AL700150

11

17

Lever

AL51493830

1

18

Knob

AL514942

1

19

Switch

AL514329

1

20

Grip Fix

AL526521

2

21

Audible Switch Assembly

AL521339

1

22

Lever Plastic

AL514682

1

23

Screw

AL511693

2

24

Pin Roll

AL700661

2

25

Bolt

AL700844

4

26

Bracket - RH

AL51486301

1

27

Bracket - LH

AL51486701

1

28

Bracket - RH

AL51486201

1

29

Bracket - LH

AL51486401

1

30

Screw

AL701375

8

31

Nut

AL700276

8

32

Nut

AL321126

2

33

Bolt

AL703892

6

ITEM NO.

DESCRIPTION.

PART NO.

QTY.

ITEM NOTE.
