Dimension Table
- 4 -
www.elitescreens.com
Nominal
Case
Screen
View
Weight
Bottom
Screen Material
View
Overall
End Cap
End Cap
Distance from
Model
Diagonal &
Length
Width
Width
Bar
Edge
to Weight Bar
Height
Height
Height
Width
Screen material
Aspect Ratio
(A)
(A1)
(A2)
Length (A3)
Distance (B4)
Height (B3)
(B1)
(B)
(B5)
(C)
to wall (C1)
M85XWS1-SRM
85" (1:1)
1677
1603
1527
1673
62
1703
1527
1795
92
79.5
20
M99NWS1-SRM
99" (1:1)
1938
1854
1778
1934
62
1954
1778
2046
92
79.5
20
M113NWS1-SRM
113" (1:1)
2192
2106
2030
2188
62
2206
2030
2298
92
79.5
20
M84NWV-SRM
84" (4:3)
1867
1783
1707
1863
62
1456
1280
1548
92
79.5
20
M100NWV1-SRM
100" (4:3)
2192
2108
2032
2188
62
1700
1524
1792
92
79.5
20
M120XWV2-SRM
120" (4:3)
2598
2514
2438
2594
62
2005
1829
2097
92
79.5
20
Unit: mm
Can't find size and ratio you’re looking for? Visit elitescreens.com/csr to create your own
Nominal
Case
Screen
View
Weight
Bottom
Screen Material
View
Overall
End Cap
End Cap
Distance from
Model
Diagonal &
Length
Width
Width
Bar
Edge
to Weight Bar
Height
Height
Height
Width
Screen material
Aspect Ratio
(A)
(A1)
(A2)
Length (A3)
Distance (B4)
Height (B3)
(B1)
(B)
(B5)
(C)
to wall (C1)
M85XWS1-SRM
85" (1:1)
66.0
63.1
60.1
65.9
2.4
67.0
60.1
70.7
3.6
3.1
0.8
M99NWS1-SRM
99" (1:1)
76.3
73.0
70.0
76.1
2.4
76.9
70.0
80.6
3.6
3.1
0.8
M113NWS1-SRM
113" (1:1)
86.3
82.9
79.9
86.1
2.4
86.9
79.9
90.5
3.6
3.1
0.8
M84NWV-SRM
84" (4:3)
73.5
70.2
67.2
73.3
2.4
57.3
50.4
60.9
3.6
3.1
0.8
M100NWV1-SRM
100" (4:3)
86.3
83.0
80.0
86.1
2.4
66.9
60.0
70.6
3.6
3.1
0.8
M120XWV2-SRM
120" (4:3)
102.3
99.0
96.0
102.1
2.4
78.9
72.0
82.6
3.6
3.1
0.8
Unit: inch
Can't
find
size
and
ratio
you’re
looking
for?
Visit
elitescreens.com/csr to create your own
The listed measurements are for general reference only. Please contact Elite Screens to verify product design and dimensions before attempting to integrate its products with any structural or furniture modification.
Although a manufacturer may offer product advice, it may be taken or disregarded at the integrator’s discretion. Elite Screens will not be held responsible or be otherwise liable for faulty installations.
A
A1
A2
B1
B3
B
B4
A3
B5
C
C1
92
79.5
20.5
Ш10.5
Ш5
10
15
11
Unit:mm
