Roland PDX-6 Dual-Trigger Mesh V-Pad - Manual

Contents of the Package
* PDX-8 or PDX-6 (pad unit)
* Connection Cable
* Drum Key
) Owner’s Manual (this manual)
Names of Components
Tuning Bolt
Head
Head Sensor Hoop Rubber
Knob Bolt
Shell
Rim Sensor
TRIGGER OUTPUT Jack
Holder
VERY IMPORTANT!
5 BEFORE playing the pad, you must tension the head. See p. 4.
5 Trigger type and trigger parameters in the sound module must be adjusted. See p. 5.
V-PAD
PDX-8
V-PAD
PDX-6
Owner’s Manual
*5100044980-03*
