PDPMV1 ♦ ProLinx Gateway Reference
PROFIBUS DPV1 Master Protocol Manual
ProSoft Technology, Inc. Page 129 of 157
March 23, 2011
Connecting the comDTM to the Master to Establish Communication
Note: The features described in this section require the current version of PROFIBUS comDTM.
You can always download the newest version from www.prosoft-technology.com.
1 From the Windows S
TART button, navigate to P ROGRAMS > P RO S OFT
T ECHNOLOGY , and then choose P RO S OFT T RANSPORT P ATH E DITOR .
2 If you have not created a communication path, click the A DD button. If you
have already created a path, skip to step 5.
3 For PTQ-PDPMV1 and ProLinx-PDPMV1 users: Select the E THERNET tab,
and enter the IP Address of the module or gateway. Enter a descriptive path
name.
Note: Do not include the underscore ( _ ) for the path name.
