Requirements for the Installation SMA Technologie AG
Page 14 SB5000TL-12:SE2006 Installation Guide
Important for the selection of the location:
Please make sure there is a sufficient space for heat dissipation! In a normal environ-
ment the following clearances should be provided for the Sunny Boy 5000TL Multi-
String:
In a living area the Sunny Boy 5000TL Multi-String
should not be mounted on plaster panels etc. in order
to avoid noises.
We recommend to install the inverter on a firm and
sturdy surface.
The Sunny Boy 5000TL Multi-String will emit a slight
noise during operation. This noise can be annoying
when the Sunny Boy is installed within a living area.
Unintended removal of the PV plug connectors can damage the
connectors and even result in serious injuries. Install the Sunny Boy
5000TL Multi-String at a place where an unintended removal of the
PV plug connectors (e. g. by children) is not possible.
Some parts of the Sunny Boy can reach temperatures over 60 °C.
Do not install the Sunny Boy on flammable construction materials,
in areas where highly inflammable materials are stored or in po-
tentially explosive environments!
Minimum clearances
Lateral 20 cm
Top 20 cm
Bottom 20 cm
Front 5 cm
20 cm 20 cm
20
cm
20
cm
5
cm
