Power Edge LB7 EZ Getting Connected
Supplied Items:
1. Power Edge EZ Module
2. Three Wire Ties
3. Two Velcro Strips
4. Power Adjustment Switch
Required Tools:
None
Please read these instructions completely so that you understand each step prior
to installation
.
The Power Edge LB7 EZ Module
This picture shows the Power Edge LB7 EZ Module with the harness cable.
This cable is
where the toggle
switch that
changes power
levels gets
connected.
These two
connectors
are EGT
thermocouple
connections.
The EZ does
not utilize
these two
wires—they
are for the
Juice product
only.
