60 Switcher Products — Protocols Manual
Section 2 — Editor Protocol
Kalypso Effects Addresses
Valid effects addresses used by Kalypso systems for the Pushbutton
Control commands are defined in
Table 44 .
Zodiak Effects Addresses
Valid effects addresses used by Zodiak systems for the Pushbutton Control
commands are defined in
Table 45 .
Table 44. Kalypso Effects Addresses - Pushbutton Select and Control
Effects Address Assignment
00 PGM-PST
01 Mix/Effects 1
02 Mix/Effects 2
03 Mix/Effects 3
0B Master E-MEM
04 PGM-PST Secondary Partition
a
a New effects address assignment associated with Kalypso.
05 Mix/Effects 1 Secondary Partition a
06 Mix/Effects 2 Secondary Partition a
07 Mix/Effects 3 Secondary Partition a
Table 45. Zodiak Effects Addresses - Pushbutton Select and Control
Effects Address Assignment
00 PGM-PST
01 Mix/Effects 1
02 Mix/Effects 2
03 Mix/Effects 3
04 DSK a
a Function associated only with Zodiak.
0B Master E-MEM
