Section 1 — Tally Protocol
Characters are limited to 7-bit ASCII. Names shorter than 12 characters are
left justified and null (0) filled. The message format is indicated in
Table 7 .
Table 7. Source Names
b7 b6 b5 b4 b3 b2 b1 b0 Notes
Source Name (0xC) Nameset ID
Nameset ID
1 – Name & Nickname
2 – Alias
Source Name (0xC) Nameset ID
Source ID (1 – 128)
0 Name Character 1 Left-most character
0 Name Character 2
0 Name Character 3
0 Name Character 4
0 Name Character 5
0 Name Character 6
0 Name Character 7
0 Name Character 8
0 Name Character 9
0 Name Character 10
0 Name Character 11
0 Name Character 12 Right-most character
0 Nickname Character 1 Left-most character
0 Nickname Character 2
0 Nickname Character 3
0 Nickname Character 4
0 Nickname Character 5
0 Nickname Character 6 Right-most character
