☆ Struction & components:
●
whole structure:
- 5 -
1.Main pole; 2.Assistant lamp Arms; 3.assistant lamps;
4.drawer(once Push to rebound , twice push to recover.
Attention:don’t pull it out of the position with heavy strength);
5.Infrared Receiver Window; 6.CCD outshell; 7.CCD Cover;
8.Baselight; 9.Back Connections; 10.Side connections; 11.Control
Panel.
●
back/side connections:
1
3
2
4
5
6
7
8
11
3
2
9
10
1 2 3
4
5 6
7
8
9
10
11
13
14
15
12
