Cavity Car-
tridge
Fuse
Mini-
Fuse Description
9 40 Amp
Green — Headlights
10 30 Amp
Pink — Ignition Switch Run Feed
11 — 20 Amp
Yellow Auto Shutdown Relay
(ASD)
12 — 20 Amp
Yellow Cigar Lighter
13 — 15 Amp
Blue Hazard Flasher
14 — 20 Amp
Yellow Auto Shutdown Relay
(ASD)
15 — 20 Amp
Yellow Rear Window Defogger
(EBL)
16, 17 — 20 Amp
Yellow Selectable Power Outlet
Cavity Car-
tridge
Fuse
Mini-
Fuse Description
18 — 15 Amp
Blue Ignition Off Draw (IOD)
19 — 15 Amp
Blue Horn
20 — 15 Amp
Blue Air Conditioning (A/C)
Clutch Relay
21 — 15 Amp
Blue STOP LIGHT Switch
22 — 25 Amp
Clear Fuel Pump/Powertrain
Control Module (PCM)
23, 24 — 10 Amp
Red Airbag
60, 61 — 15 Amp
Blue Ignition Run/Start Relay
Feed
62, 63 — 15 Amp
Blue Gauges
MAINTAINING YOUR VEHICLE 231
7
