ENGLISH
FOREWORD
This section must be read before any connection is made to the mains
supply.
WARNINGS
Do not expose the equipment to rain or moisture.
Do not remove the cover from the equipment.
Do not push anything inside the equipment through the ventila-
tion holes.
Do not handle the mains lead with wet hands.
EQUIPMENT MAINS WORKING SETTING
Your Marantz product has been prepared to comply with the household
power and safety requirements that exist in your area.
“/02” Version product can be powered by 230 V AC only.
On the rear panel of the “/01” Version product, a voltage selector (2-
position) is provided. Be sure to set the voltage selector to the mains
voltage of your area before using the unit.
IMPORTANT: (For UK version only)
This apparatus is fitted with an approved moulded 13 Amp plug.
To change a fuse in this type of plug proceed as follows:
1. Remove fuse cover and fuse.
2. Fix new fuse which should be a BS1362 5A, A.S.T.A. or BSI ap-
proved type.
3. Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should be cut off
and an appropriate plug fitted in its place.
If the mains plug contains a fuse, this should have a value of 5A. If a
plug without a fuse is used, the fuse at the distribution board should not
be greater than 5A.
NOTE:
The severed plug must be destroyed to avoid a possible shock hazard
should it be inserted into a 13A socket elsewhere.
HOW TO CONNECT A PLUG
The wires in the mains lead are coloured in accordance with the follow-
ing code:
BLUE—“NEUTRAL” (“N”)
BROWN—“LIVE” (“L”)
1. The BLUE wire must be connected to the terminal which is marked
with the letter “N” or coloured BLACK.
2. The BROWN wire must be connected to the terminal which is marked
with the letter “L” or coloured RED.
3. Do not connect either wires to the earth terminal in the plug which
is marked by the letter “E” or by the safety earth symbol or coloured
green or green-and-yellow.
Before replacing the plug cover, make certain that the cord grip is
clamped over the sheath of the lead — not simply over the two wires.
COPYRIGHT
Recording and playback of any material may require consent. For fur-
ther information refer to the following:
— Copyright Act 1956
— Dramatic and Musical Performers Act 1958
— Performers Protection Acts 1963 and 1972
— any subsequent statutory enactments and orders
ABOUT THIS USER GUIDE
Refer to the Figures on the page 57 at the rear of this user guide. The
numbers on the diagrams correspond to those in the text. All references
to the connections and controls that are printed in
BOLD type are as
they appear on the unit.
PRECAUTIONS
The following precautions should be taken when operating the equip-
ment.
GENERAL PRECAUTIONS
When setting the equipment ensure that:
— the ventilation holes are not covered
— air is allowed to circulate freely around the equipment
— it is on a vibration free-surface
— it will not be exposed to interference from an external source
— it will not be exposed to excessive heat, cold, moisture or dust
— it will not be exposed to direct sunlight
— it will not be exposed to electrostatic discharges
Never place heavy objects on the equipment.
If a foreign body or water does enter the equipment, contact your near-
est dealer or service centre.
Do not pull out the plug by pulling on the mains lead, hold the plug.
It is advisable when leaving the house, or during a thunderstorm, to
disconnect the equipment from the mains supply.
CONNECTIONS
(Figure 2)
CONNECTIONS OF TUNER
Connect the output jacks of your stereo tuner to the LINE 1-LINE 3
jaclks of this unit.
CONNECTION OF COMPACT DISC PLAYER
Connect the output jacks of your CD player to the CD jacks of this unit.
CONNECTION OF TURNTABLE
Connect the L (Left) output cord of the turntable to the “ L ” PHONE jack
of this unit, and connect the R (Right) output cord to the “ R ” PHONE
jack. Also be sure to connect the turntable's grounding wire to the GND
jack of this unit. The GND jack does not have to be connected if the
turntable is not provided with a grounding wire.
CONNECTION OF DCC/TAPE DECK
Connect the IN (recording input) jacks of the tape deck to the OUT
jacks of this unit, and connect the OUT (playback output) jacks of the
tape deck to the
IN jacks of this unit.
CONNECTION OF SPEAKER SYSTEMS
This unit is equipped with a sets of SPEAKER SYSTEM terminals.
• The speakers in the speaker system should have an impedance be-
tween 4 and 16 ohms. If speakers with an impedance of less than 4
ohms are connected, the protection circuitry may be activated during
play.
• Connect the Right channel speaker to the R terminals, and the Left
channel speaker to the L terminals.
• The output terminaks have positive (+: Red) and negative (–: Black)
polarity, and each speaker slso has the same polarity (+ and –). When
connecting the speaker, be sure to connect the terminals with the
same polarity (+with +, – with –).
