DESCRIPTION AND OPERATION
The RT1 is a time switch that turns OFF the connected light or fan when the
selected time expires. The pilot light behind the ON/OFF button and the time
delay indicator light illuminates while the switch is OFF. When the switch is ON,
the pilot light behind the ON/OFF button turns OFF.
Manual ON
Turn ON the connected light or fan by pressing the desired time button, or the
ON/OFF button. If you press the ON/OFF button, it activates the time delay that
was last used.
Manual OFF
While the timer is active, you can press the ON/OFF button to turn OFF the
connected light or fan without delay.
Changing the selected time
If you decide that you need more or less time than you originally selected,
restart the time switch by pressing the button that matches the amount of time
you think you’ll need.
Call 800.223.4185 for Technical Support
