Page 3
3
ENGLISH
Screen size
(diagonal)
16 : 10 screen
4 : 3 screen
Projection distance
Screen
height
Screen
height
Projection distance
Screen
height
Screen
height
min.
max.
min.
max.
type
(inch) m
m inch
m
inch cm inch cm inch
m inch
m
inch cm inch cm inch
30
0.8 0.9
36
1.1 44
40
16
1
0
1.1 41
1.3 50
45
18
1
0
40
1.0 1.2
49
1.5 59
53
21
1
0
1.4 56
1.7 67
60
24
1
0
50
1.3 1.6
61
1.9 74
66
26
1
1
1.8 70
2.1 84
75
31
2
1
60
1.5 1.9
74
2.3 89
79
31
2
1
2.1 84
2.6 101 90
37
2
1
70
1.8 2.2
86
2.6 104 92
36
2
1
2.5 98
3.0 118 105 43
2
1
80
2.0 2.5
99
3.0 119 106 42
2
1
2.8 112 3.4 135 119 49
2
1
90
2.3 2.8 111 3.4 134 119 47
2
1
3.2 126 3.9 152 134 55
3
1
100 2.5 3.1 124 3.8 149 132 52
3
1
3.6 140 4.3 169 149 61
3
1
120 3.0 3.8 149 4.5 179 158 62
3
1
4.3 169 5.1 203 179 74
4
1
150 3.8 4.7 186 5.7 224 198 78
4
2
5.4 211 6.4 254 224 92
5
2
200 5.1 6.3 249 7.6 299 264 104
5
2
7.2 282 8.6 338 299 123
6
2
250 6.4 7.9 311 9.5 374 330 130
7
3
9.0 352 10.8 423 373 153
8
3
300 7.6 9.5 374 11.4 449 396 156
8
3
10.7 423 12.9 508 448 184
9
4
On a horizontal surface
Suspended from the ceiling
• Keep a space of 30 cm or more
between the sides of the projector and
other objects such as walls.
• Consult with your dealer before a
special installation such as suspending
from a ceiling.
WARNING ►Install the projector in a stable horizontal position.
►Place the projector in a cool place, and ensure that there is sufficient ventilation.
►Do not place the projector anyplace where it may get wet.
CAUTION ►Avoid placing the projector in smoky, humid or dusty place.
►Position the projector to prevent light from directly hitting the projector’s
remote sensor.
b
a
b
c1
c1
c2
c2
Arrangement
Refer to the illustrations and tables below to determine screen size and projection distance.
The values shown in the table are calculated for a full size screen: 1280×800
a
Screen size (diagonal)
b
Projection distance (±10%)
c1
,
c2
Screen height (±10%)
