34
Connecting to the PC (DVI)
Turn the PC on.
Press the PC or ( ) button on the remote control to select
the PC.
Set up the PC software. (See page 35)
Adjust the screen in PC Mode. (See page 26 ~ 27)
1
2
3
4
Rear of the TV
Audio Cable (Not Included)
DVI Cable (Not Included)
Rear of the PC
◆ Connect the DVI Cable to the DVI INPUT port on the TV and
output port on the Rear of the PC.
DVI INPUT
Rear of the TV
Audio Cable (Not Included)
15Pin D-Sub Cable
Rear of the PC
◆ Connect the 15Pin D-Sub Cable to the RGB INPUT port on the TV and
output port on the Rear of the PC.
RGB INPUT
To use the TV as a PC Display
Input Selection
1. TV
2. SCART1 RGB
3. SCART2 RGB
4. AV2 VIDEO
5. AV2 S-VIDEO
6. COMPONENT1
7. COMPONENT2
8. RGB
9. DVI
