ADP-L2DXT User’s Manual
8
1.3
Connector: CN_LVDS_IN
Type: HIROSE DF13-20S
Connector: DC_IN
Type: DF14 2-pin pitch=1.25mm
Connector: CN_LVDS_OUT
Type: HIROSE DF13-20S
Pin Description Pin Description
1 LCDVCC 2 LCDVCC
3 GND 4 GND
5 RX0N 6 RX0P
7 GND 8 RX1N
9 RX1P 10 GND
11 RX2N 12 RX2P
13 GND 14 RXLCKN
15 RXLCKP 16 GND
17 SPC (SMBUSCLK) 18 SPD (SMBUSDATA)
19 GND 20 Will be defined
Pin Description Pin Description
1 GND 2 +5V
Pin Description Pin Description
1 LCDVCC 2 LCDVCC
3 GND 4 GND
5 TXL0N 6 TXL0P
7 GND 8 TXL1N
9 TXL1P 10 GND
11 TXL2N 12 TXL2P
13 GND 14 TXLCKN
15 TXLCKP 16 GND
17 TXL3N 18 TXL3P
19 GND 20 GND
20
1 2
1
1
2
19
2
19
20
