DATASHEET
DS_Q48DR1R533_03152007

Delphi Series Q48DR, 87W-100W, Quarter Brick
Dual Output, DC/DC Power Modules:
48V in, 1.5V and 3.3V, 15A out each channel

The Delphi Series Q48DR Quarter Brick Dual, 48V input, dual output,
isolated DC/DC converters are the latest offering from a world leader in
power system and technology and manufacturing -- Delta Electronics,
Inc. This product family provides up to 100 watts of power or 15A of
output current (each channel simultaneously) in an industry standard
footprint. Both output channels can be used independently of each other
with option to trim each channel either in the same direction or in
reversion direction. With creative design technology and optimized
circuit, these converters possess outstanding electrical and thermal
performance, as well as extremely high reliability under highly stressful
operating conditions. All the models are fully protected from abnormal
input/output voltage, current, and temperature conditions. The Delphi
Series converters meet all safety requirements with basic insulation.

APPLICATIONS

Telecom/DataCom

Wireless Networks

Optical Network Equipment

Server and Data Storage

Industrial/Test Equipment

OPTIONS

Optional second trim pin for

independent trim of the two outputs.

Positive On/Off logic

Short pin lengths available

FEATURES

High Efficiency: 87.5%@1.5V/15A, 3.3V/15A

Standard footprint: 57.9mmx36.8mmx8.5mm

(2.28”Ч1.45”Ч0.33”)

Industry standard pin out

2:1 input voltage range

Fixed frequency operation

Fully protected: OTP, OCP, OVP, UVLO

No minimum load required

1500 V isolation and Basic insulation

Two independent power train and separate

trim for each output

ISO 9001, TL 9000, ISO 14001, QS 9000,

OHSAS 18001 certified manufacturing facility

UL/cUL 60950 (US & Canada) Recognized,

and TUV (EN60950) Certified

CE mark meets 73/23/EEC and 93/68/EEC

directives
