TME-104P-CMx-GF-1V7 Rev 1.7 35 (81)
Audio Connector (X1)
Connector type IDC 16-pin header, 2.00mm
Adapter cable Article number 862-0065-10
Pin Signal Pin Signal
1 LineOut_R 2 LineOut_L
3 Surround_R 4 Surround_L
5 LFE 6 Center
7 GND_Audio 8 GND_Audio
9 LineIn_R 10 LineIn_L
11 MIC_R 12 MIC_L
13 GND 14 GND
15 S/P_DIF_IN 16 S/P_DIF_OUT
GPIO and FAN (X2)
Connector type IDC 16-pin header, 2.00mm
Pin Signal Pin Signal
1 FCH_GEVENT0 2 FCH_GPIO52
3 FCH_GPIO61 4 FCH_GPIO62
5 FCH_GPIO187 6 FCH_GPIO188
7 FCH_GPIO189 8 FCH_GPIO190
9 FCH_GPIO191 10 FCH_GPIO192
11 SIO_PWM1 12 SIO_FANTACH1
13 SIO_ADC_5V_IN 14 SIO_ADC_12V_IN
15 GND 16 +3.3V/0.5A output
Caution: older PCB revisions placed the pin-1 marker on the wrong pin. Regardless of which is marked, pin 1
is the pin closest to the power connector.
FCH :
AMD A55E (Hudson-E1) is AMD’s first generation Fusion Controller Hub (FCH)
SIO : SMSC SCH3112 Super I/O
