Page 35: 5 on-board power supply
TME-104P-CMx-GF-1V7
Rev 1.7
27 (81)
Ethernet Connector (X10)
Connector type
IDC 10-pin header, 2.00 mm
Adapter cable
Article number 862-0018-10
Pin
Signal
Pin
Signal
1
ETH_MX0n
2
ETH_MX0p
3
ETH_MX1n
4
ETH_MX1p
5
NC
6
KEY
7
ETH_MX2n
8
ETH_MX2p
9
ETH_MX3n
10
ETH_MX3p
3.5 On-Board Power Supply
The on-board power supply generates all necessary voltages from the single supply voltage of 5 volts. The
generated 3.3 volts are available on the connectors "Flat Panel" and "LVDS".
Note
This 3.3V must not be used to supply external electronic devices with high-power
consumption like other PC/104 boards or displays.
Power Connector (X21)
Connector type
JST B15B-EH-A, 15-pin
Adapter cable
Article number 862-0044-10
Pin
Signal (standard)
Signal (5V only)
1
+5V
+5V
2
GND
GND
3
+5V
+5V
4
GND
GND
5
+5V
+5V
6
+5V Standby
NC
7
GND
GND
8
PSON#
GND
