GENERAL
INFORMATION
Section 1 — General Information
Carrier Air-cooled 7 kW, 12 kW and 15 kW Generators
1.5 SPECIFICATIONS
♦ 1.5.1 GENERATOR
Model ASPAS1CCA007 ASPAS1CCA012 ASPAS1CCA015
Rated Max. Continuous Power Capacity (Watts*) 6,000 NG/7,000 LP 12,000 NG/12,000 LP 13,000 NG/15,000 LP
Rated Voltage 120/240 120/240 120/240
Rated Max. Continuous Load Current (Amps)
120 Volts** 50.0 NG/58.3 LP 100.0 NG/100.0 LP 108.3 NG/125.0 LP
240 Volts 25.0 NG/29.2 LP 50.0 NG/50.0 LP 54.2 NG/62.5 LP
Main Line Circuit Breaker 30 Amp 50 Amp 65 Amp
Phase
1 1
1
Number of Rotor Poles 2 2 2
Rated AC Frequency 60 Hz 60 Hz 60 Hz
Power Factor
1 1
1
Recommended Air Filter Carrier Part # 0C8127 Carrier Part # 0C8127 Carrier Part # 0C8127
Battery Requirement Group 26 Group 26 Group 26
(At 0° F-17.8° C) 12 Volts and 12 Volts and 12 Volts and
350 Cold-cranking 525 Cold-cranking 525 Cold-cranking
Amperes Minimum Amperes Minimum Amperes Minimum
Weight 375 Pounds 470 Pounds 487 Pounds
Output Sound Level @ 23 ft (7m) at full load 68 db (A) 70.5 db (A) 71.5 db (A)
Normal Operating Range -20°F (-28,8°C) to 104°F (40°C)
^ Maximum wattage and current are subject to and limited by such factors as fuel Btu content, ambient temperature, altitude, engine power and condition, etc. Maximum power decreases about 3.5
percent for each 1,000 feet above sea level; and also wii! decrease г^юи! 1 percent for each O’" C (10° F) above 16° C (60° F) ambient temperature.
Load current values shown for 120 volts are maximum TOTAL values for two separate circuits. The maximum current in each circuit must not exceed the value stated for 240 volts.
♦ 1.5.2 ENGINE
ASPAS1CCA007 ASPAS1CCA012 ASPAS1CCA015
Type of Engine GH-410 GT-990 GT-990
Number of Cylinders 1 2 2
Rated Horsepower 14.5 @ 3,600 rpm 30 @ 3,600 rpm 30 @ 3,600 rpm
Displacement 410cc 992cc 992cc
Cylinder Block Aluminum w/Cast Aluminum w/Cast Aluminum w/Cast
Iron Sleeve Iron Sleeve Iron Sleeve
Valve Arrangement Overhead Valves Overhead Valves Overhead Valves
Ignition System Solid-state w/Magneto Solid-state w/Maqneto Solid-state w/Magneto
Recommended Spark Plug RC14YC RC12YC RC12YC
Spark Plug Gap 0.76 mm (0.030 inch) 0.508 mm (0.020 inch) 0.508 mm (0.020 inch)
Compression Ratio 8.5:1 9.5:1 9.5:1
Starter 12 Vdc 12 Vdc 12Vdc
Oil Capacity Including Filter Approx. 1.5 Qts Approx. 1.7 Ots Approx. 1.7 Ots
Recommended Oil Filter Carrier Part # 70185D Carrier Part # 70185D Carrier Part # 70185D
Recommended Air Filter Carrier Part # 0C8127 Carrier Part # 0C8127 Carrier Part # 0C8127
Operating RPM 3,600 3,600 3,600
1.6 SYSTEM SET LED
The “System Set” LED is lit when all of the following
conditions are true:
f. The AUTO/OFF/MANUAL switch is set to the AUTO
position.
2. The utility voltage being supplied to the unit is being
sensed by the PCB. If the utility sense voltage is not
connected to the unit or if it is below 168 volts AC,
then the system set light will flash rapidly. This
indicates that if the AUTO/OFF/ MANUAL switch is
placed in the Auto position, the generator will start.
3. The “Not In Auto” dip switch is set to the OFF position
on the control board.
0 Carrier
4. No alarms are present, for example, low oil pressure,
high temperature, etc.
1.7 FUEL REQUIREMENTS
AND RECOMMENDATIONS
With LP gas, use only the vapor withdrawal
system. This type of system uses the vapors formed
above the liquid fuel in the storage tank. The engine has
been fitted with a fuel carburetlon system that meets the
specifications of the 1997 California Air Resources Board
for tamper-proof dual fuel systems. The unit will run on
natural gas or LP gas, but it has been factory set to run
on natural gas.
