Ethernet + DC Copper Port 1 x 10/100Base-TX with IEEE 802.3af PoE PD for data + DC in
RJ-45 connector
Ethernet Copper Port 1 x 10/100Base-TX for data out
RJ-45 connector
Power over Ethernet
PoE Standard IEEE 802.3af Power over Ethernet / PD
PoE Input Pin Assignment 1/2(+), 3/6(-) End-Span or 4/5(+), 7/8(-) Mid-Span
PoE Input Voltage 48 VDC ( Range 44 to 56 VDV)
Hardware Specification
Data Rate 10/100 Mbps (vary on Ethernet device attached)
Throughput (Packet per second) 148810 pps@64 Bytes
DIP Switch 5 VDC / 12 VDC output voltage
Output DC Connector DC Jack 5.5 x 2.5 mm receptacle in the central post
Output Power 12 W max
Number of Devices that can be
powered 1
Ethernet Cable TIA/EIA-568, Category 5/5e cable
Installation Standalone or Wall mountable
Material Plastic
Standards Conformance
Standard Compliance IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 10/100Base-TX Fast Ethernet
IEEE 802.3af Power over Ethernet PD
Physical Specifications
Dimensions (W × D × H):
2.87” x 2.17” x 0.94” / 73 x 55 x 24 mm
Weight:
0.22 lbs / 50 g
Environmental Specifications
Operating:
Temperature: 0°C to 50°C
Relative Humidity: 5% to 90% (non-condensing)
4 SP-PoE Splitter User Manual
