Parts & assembly sheet, Parts list – Golden Lighting 4002-1W RSB User Manual

Page 2

Mounting Strap

1ea

Mounting
Screws

4ea

Deco Nut

1ea

Hex nut

2ea

Wire
connectors

3ea

Green Screw

1ea

Part Needed

Quantity

Part Needed

Quantity

Reason why

( missing, scratched, broken glass, bent, bad finish)

Comments

PARTS & ASSEMBLY SHEET

This fixture assembled PO:__________ Date: ________

Fixture Name: Loretto 4002-1W RSB

Notice:

Please review the parts listing and check for all parts before assembling the fixture. If any

parts are missing or damaged, please note onthis sheet and contact the place of purchase to arrange
for replacement parts.

PARTS LIST

Company Name:_______________________Co. Account #:__________
below to be filled out by retailer

4002-1W RSB

Read and review installation instruction sheet
before assembling the fixture.

IXTURE

SSEMBLY

NSTRUCTIONS

For Customer Service, contact the place of purchase to arrange for replacement parts.

NOTE: I

NSTALL THE GLASS ASSEMBLY

AFTER THE FIXTURE IS HUNG.

1. Place the Glass Shade (F) over the Threaded Socket
(G)
2. Holding the Glass Shade ( F ), and secure it by
threading the Socket Ring ( H ) onto the Threaded
Socket ( G ) until tight .
3. Install the light bulbs in accordance with the
fixture's specification .

(DO NOT EXCEED THE MAXIMUM WATTAGE RATING!)

Fig. 4
