3-4 Command Parameter List
3-28
- CC-Link Compatible Network Unit DL-CL1 User’s Manual (FD-MH) -
Co
mm
u
ni
c
a
ting
w
ith t
he FD
-M
H
s
er
ie
s
3
00
nn40
Group-2 entry
count
R
-
8
nn41
Instantaneous
flow rate setting 1
(P1)
*7
R/W
FD-MH10A
03.00
00.00 to 30.00
FD-MH50A
015.0
000.0 to 100.0
FD-MH100A
030.0
000.0 to 200.0
FD-MH500A
100.0
000.0 to 999.9
nn42
Instantaneous
flow rate setting 2
(P2)
*7
R/W
FD-MH10A
10.0
00.00 to 30.00
FD-MH50A
050.0
000.0 to 100.0
FD-MH100A
100.0
000.0 to 200.0
FD-MH500A
200.0
000.0 to 999.9
nn43
Temperature
upper limit setting
*8
R/W
-
080.0
100.0: Disable upper limit detection
0.001 to 099.9: Upper limit value
nn44
Temperature
lower limit setting
*9
R/W
-
005.0
000.0: Disable lower limit detection
0.001 to 099.9: Lower limit value
nn45
Integrated flow
quantity setting 1
R/W
-
0150
0000 to 9999
nn46
Integrated flow
quantity setting 2
R/W
-
9999
0000 to 9999
nn47
Instantaneous
flow rate setting 3
(P3)
*7
R/W
FD-MH10A
13.00
00.00 to 30.00
FD-MH50A
065.0
000.0 to 100.0
FD-MH100A
130.0
000.0 to 200.0
FD-MH500A
400.0
000.0 to 999.9
nn48
Instantaneous
flow rate setting 4
(P4)
*7
R/W
FD-MH10A
20.00
00.00 to 30.00
FD-MH50A
100.0
000.0 to 100.0
FD-MH100A
200.0
000.0 to 200.0
FD-MH500A
500.0
000.0 to 999.9
nn49 to
nn5F
System reserved
nn60
Group-3 entry
count
R
-
5
nn61
Key lock function
R/W
-
0
0: Deactivate key lock
1: Key lock
nn62
System reserved
nn63
Analog output
selection
*10
R/W
-
0
0: Standard
1: Free range analog
nn64
Free range analog
upper limit
*10
R/W
FD-MH10A
10.0
0.0 ~ 30.00 (Settable unit: 0.1)
FD-MH50A
050
000 to 100 (Settable unit: 5)
FD-MH100A
100
000 to 200 (Settable unit: 10)
FD-MH500A
0500
0000 to 1000 (Settable unit: 50)
nn65
Free range analog
lower limit
*10
R/W
FD-MH10A
0.0
0.0 ~ 30.00 (Settable unit: 0.1)
FD-MH50A
000
000 to 100 (Settable unit: 5)
FD-MH100A
000
000 to 200 (Settable unit: 10)
FD-MH500A
0000
0000 to 1000 (Settable unit: 50)
nn66 to
nn7F
System reserved
nn80
Group-4 entry
count
R
-
29
nn81
System reserved
nn82
Detection mode
R/W
-
0
0: F-1
1: F-2
2: F-3
3: A-1
4: A-2
Data
category
(HEX)
Data
number
(HEX)
Name
Description
Attribute
Sensor head
Default
value
Parameter range
