3-4 Command Parameter List
3-27
3
Co
mm
u
ni
c
a
ting
w
ith t
he FD
-M
H
s
er
ie
s
- CC-Link Compatible Network Unit DL-CL1 User’s Manual (FD-MH) -
00
nn24
Control output,
integration pulse
output, error alarm
output states
*2 R - -
Bit 0: Output 1
Bit 1: Output 2
Bit 2: Output 3
Bits 3 to 15: Always 0
nn25
Instantaneous flow
rate
(current value)
*3 R
FD-MH10A
-
00.00 to 99.99
FD-MH50A
FD-MH100A
000.0 to 999.9
FD-MH500A 0000.0 to 9999.9
nn26
Integrated flow
quantity
*4 R
FD-MH10A
-
0000000.00 to 4294967.29
FD-MH50A
FD-MH100A
00000000.0 to 42949672.9
FD-MH500A 000000000 to 429496729
nn27
Instantaneous flow
rate
(peak hold value)
*3 R
FD-MH10A
-
00.00 to 99.99
FD-MH50A
FD-MH100A
000.0 to 999.9
FD-MH500A 0000.0 to 9999.9
nn28
Instantaneous flow
rate
(bottom hold
value)
*3 R
FD-MH10A
-
00.00 to 99.99
FD-MH50A
FD-MH100A
000.0 to 999.9
FD-MH500A 0000.0 to 9999.9
nn29 to
nn2A
System reserved
nn2B
Bank switching
state
R - -
0: Bank A
1: Bank B
nn2C System reserved
nn2D
Current
temperature
*5 R - - 000.0 to 999.9
nn2E
Temperature
(peak hold value)
*5 R - - 000.0 to 999.9
nn2F
Temperature
(bottom hold
value)
*5 R - - 000.0 to 999.9
nn30 to
nn33
System reserved
nn34
External Input
Status
R - -
0: OFF
1: ON
nn35 System reserved
nn36
Temperature
sensor
connection
*6 R - -
0: Not connected
1: Connected
nn37 to
nn3F
System reserved
Data
category
(HEX)
Data
number
(HEX)
Name Description Attribute Sensor head
Default
value
Parameter range
