N525 Ethernet Termination Service Unit
4. Type 2 for "CLD Profile" and press
This screen has VLAN and Ping parameters.
a. VLAN Tagging
Enable or disable VLAN tagging of the Ping packets used for CLD.
b. VLAN ID
VLAN ID to use if VLAN tagging is enabled. 1 – 4094.
c. VLAN PCP
VLAN Priority Code Point (frame priority level). 0 – 7.
d. Packet DSCP
Value of the DiffServ Differentiated Services Code Point, if needed. 0 – 63.
e. Packet Payload Size (40 - 1472)
Payload size of the Ping packets used for CLD.
f. Packet Interval (ms)
Interval in milliseconds between each Ping packet.
g. Packet Timeout (ms)
Number of milliseconds to wait before timing out a Ping packet.
5. Press
-----------------------------------CLD PROFILE---------------------------------
1) VLAN Tagging : Enabled
2) VLAN ID : 1000
3) VLAN PCP : 0
4) Packet DSCP : 0
5) Packet Payload Size (40 1472) : 1472
6) Packet Interval (ms) : 60
7) Packet Timeout (ms) : 10
Select [1 7]:
-----------------------------------Messages------------------------------------
