SubliJet-R: Ricoh SG 3110DN - PowerDriver-R
Setup and Print Guide: Elements 8, 9 & 10
PAGE 3 of 4 >>
4. Also, once an image has been opened or imported in Elements, you will need to configure the embedded
profile. In the menu bar, click Image > Convert Color Profile > Convert to sRGB Profile (see FIGURE 4).
FIGURE 4
Printing from Elements with PowerDriver R SG3110DN
5.) With the correct Color settings entered, you are now ready to print. In the Menu Bar, click File > Print. In
the Print window, match your settings to those shown below (see FIGURE 5).
FIGURE 5
B. Click More Options...
C. Click Color Management
A. Select Printer: PowerDriver R SG3110DN
E
3
1
2
A
B
C
D
F
