ASSEMBLY INSTRUCTIONS
Remove 4 screws from bottom of Lower Pillar (B)
1. Locate and pull down the cable inside (B) and plug cable into the base (C).
2. Connect Upper Pillar (B) into Base (C). Secure Pillar to Base using the screws provided.
3. Attach the Tray to the Base using the 2 screws provided.
4. Tighten the screws and cover them with the provided protectors.
