11
42BVC FAN COIL WITH ELECTRIC HEAT OPTION
NOTES:
1. All dimensions are in inches (± 1 /
4
in.).
2. Any modifications to product specifications by any person are subject to acceptance of the factory. Product specifications are subject to
change without notice.
3. Right hand shown, left hand opposite.
4. Hanger rods, which are field-supplied, are shown for reference only.
UNIT
42BVC
DIMENSIONS (in.)
Fan Size Depth Width Height
Supply Duct Return Duct
A B C E F
06 9 x 4 20 28 1 /
16
36 1 /
2
7 1 /
8
10 9 /
16
3 3 /
4
24 1 /
16
16 7 /
16
08 9 x 6 20 28 1 /
16
36 1 /
2
8 9 /
16
10 9 /
16
3 3 /
4
24 1 /
16
16 7 /
16
10 10 x 4 22 37 1 /
16
39 3 /
8
7 1 /
2
11 11 /
16
5 1 /
2
33 1 /
16
18 3 /
16
12 10 x 7 22 37 1 /
16
39 3 /
8
9 15 /
16
11 11 /
16
5 1 /
2
33 1 /
16
18 3 /
16
16 11 x 10 22 47 1 /
16
39 3 /
8
13 5 /
16
12 11 /
16
16 7 /
8
43 1 /
16
18 3 /
16
20 12 x 9 24 48 1 / 16 45 1 / 8 12 1 / 2 13 3 / 4 17 13 / 16 44 1 / 16 20 11 / 16
30 12 x 12 28 48 1 /
16
54 3 /
16
15 7 /
8
13 3 /
4
16 1 /
8
44 1 /
16
28 15 /
16
40 15 x 12 28 62 1 /
16
57 5 /
8
16 7 /
16
16 1 /
16
22 7 /
8
58 1 /
16
28 15 /
16
