Crestron CPC-2000A Touchpanel with Dual Joysticks
the speed. Speed can be adjusted while using the joysticks. The knobs are panel
mounted single-turn potentiometers.
Joysticks
Two 2-axis, spring centering joysticks, located beneath the sensitivity adjustment
knobs, are used to control pan, tilt, focus, and zoom movement of a network
camera/lens assembly. Vertical movement of the right-most joystick (when viewing
the touchscreen) tilts the head. Horizontal movement of the right-most joystick pans
the head. Vertical movement of the left-most joystick zooms the lens. Horizontal
movement of the left-most joystick focuses the lens.
Network Connector
This 6-pin, 6-position RJ11 modular jack, located on the back panel of the
CPC-2000A, is used to receive power and to communicate with the control system.
Use the cable assembly (supplied) to connect the CPC-2000A to the CN-RJ11
(supplied) and, in turn, connect the CN-RJ11 to the control system per the latest
revision of the network interconnection diagram (Doc. 5411). If connecting the
CPC-2000A to a CNX-series control system, the CN-RJ11 is not required. Make
connections per the latest revision of the modular cable requirements (Doc. 5682).
Leading Specifications
The two tables, shown after this paragraph, provides a summary of leading
specifications for the CPC-2000A and joystick particulars. Dimensions and weight
are rounded to the nearest hundredth unit.
Leading Specifications of the CPC-2000A
SPECIFICATION DETAILS
Power Requirements 12 Watts, 24 VDC 0.5 Amp
Default Network ID 03 (touchpanel) & 30H (joystick)
SIMPL™ Windows® Version 1.22 or later*
CNX Operating System Version 5.01.09x or later
CNX Monitor Version 2.00 or later
CNMS, CNRACK, CNLCOMP Version 3.16.08 or later
Operating System
ST-CP Operating System
Version 4.00.29 or later
ST-CP Monitor Version 1.29 or later
VisionTools™ Pro Version 1.2.1 or later*
Crestron Database Version 11.7.209 or later*
Memory 768 Kbytes flash memory for display
Dimensions Height: 4.09 in (10.40 cm)
Width: 9.00 in (22.86 cm)
Depth: 10.07 in (25.59 cm)
Weight (without CN-RJ11) 3.60 lb (1.63 Kg)
* The latest software versions can be obtained from the Downloads page (SIMPLWIN, TOUCHPNL,
and CRESDB Libraries) on the Crestron website (
www.crestron.com) . New users are required to
register in order to obtain access to the FTP site.
NOTE: In order to have CPC-2000A available from the Device Library when
programming in SIMPL Windows, use the latest version of SIMPL Windows
available from Crestron’s website or use an earlier version with library update file
smwlib58.exe and library update document smwlib58.txt or later. These update files
are available from the Downloads page (SIMPLWIN Library) of Crestron’s website.
Operations Guide - DOC. 5801A Touchpanel with Dual Joysticks: CPC-2000A • 3
