COM Express™ miniBaseboard Type 2

/ Connectors and Features



47

J60 - CPLD JTAG Connector

For CPLD programming the CPLD JTAG connector J60 is only available on ETXexpress® miniBaseboard

J7 pin

Function

J7 pin

Function

1

TCK

2

GND

3

TDO

4

+3.3V_noATX

5

TMS

6

n.c.

7

n.c.

8

n.c.

9

TDI

10

GND

J76 - CPLD Debug connector

On COM Express™ miniBaseboard Type 2 a full featured 12pin debug connector J76 is available for CPLD programming
and debugging.

J7 pin

Function

J7 pin

Function

1

+3.3V_S5

7

MCCI_DATA_IN

2

TDI

8

MCCI_RESET

3

TCK

9

MCCI_CLK

4

TMS

10

CPLD_GP1

5

TDO

11

CPLD_GP2

6

MCCI_DATA_OUT

12

GND
