Specifications MODEL 2087 TURNTABLE SERIES
20 © EMC TEST SYSTEMS, L.P. – OCTOBER 2002
REV C – PN 399233
SPECIFICATIONS
ELECTRICAL
Drive Speeds Single (Standard) Variable
(Optional)
Nominal AC Voltage 208-230 VAC 208-230 VAC
Input Frequency 50/60 Hz 50/60 Hz
Current Rating 20 amp service 20 amp service
AMP 4 8
RPM 1.9 .5/2.0
Phase
Single (1) Single (1)
MECHANICAL
Diameter 2 meters 3 meters
Height 28 cm (11 in) 28 cm (11 in)
Distributed Load
Rating * 907 kg (2000 lb) 1135 kg (2500 lb)
* Distributed Load Rating is based on load being evenly
distributed to each section. No point loads under .37 sq. m (4 sq. ft)
should exceed 500 kg (1100 lb); and not over 500 kg should be
applied to a 45 degree segment outboard of the casters.
Archived 3/18/10
