Operation MODEL 2087 TURNTABLE SERIES
14 © EMC TEST SYSTEMS, L.P. – OCTOBER 2002
REV C – PN 399233
RECOMMENDED PARAMETERS FOR THE
MODEL 2090 POSITIONING
CONTROLLER
DEVICE 2
Parameter Value Description
P1
0 Turntable
P2
0 Standard Turntable
P3
000 Infinite Scan Count
P5
1 Non-continuous rotation
P8
2.5 2.5 Second reverse delay
P9
9 Primary GPIB address 9
b1
000 User options disabled
c
3600 3600 encoder counts per meter
S0
-1 Step speed = run speed
Oc
On Overshoot compensation enabled
EDITING MODEL 2090 POSITIONING
CONTROLLER CONFIGURATION
PARAMETERS
To edit a configuration parameter, press the PARAM key to
display the current parameter. Pressing the PARAM key
repeatedly will scroll down through the parameter list, showing
each parameter in turn. While viewing a parameter, the STEP
keys (INC/DEC) may be used to scroll up or down the parameter
list. This reduces the effort necessary to scan through a long
parameter list using the PARAM key. Pressing any of the
LIMIT/POSITION selection keys will return the display to that
selection. Pressing any of the remaining motion keys will return
the display to the current position and execute that motion.
Pressing the PARAM key again will return to the last displayed
parameter in the list, allowing easy transition between parameter
adjustment and device operation.
Once the desired limit, position or parameter is visible in the
display window, pressing INCRM, DECRM, or ENTER will
