MODEL 2087 TURNTABLE SERIES Assembly Instructions
© EMC TEST SYSTEMS, L.P. – OCTOBER 2002 7
REV C – PN 399233
ASSEMBLY INSTRUCTIONS
The installation of turntables 2 meters and larger will be performed
by a factory installation specialist or by individuals who have been
authorized by ETS-Lindgren to do such work. Proper installation
of the turntable directly affects performance. The following
installation information is provided to familiarize the user of the
turntable with the installation process.
1. Uncrate all parts. Check all parts for any shipping damage.
Ensure a clear area is available to assemble the turntable unit
safely. NOTE: Do not discard any packing material until unit is
fully assembled.
2. Remove the bolts which attach the top onto the turntable drive
assembly. Make note of the placement of each top section as it
is removed. Refer to the assembly drawing in the rear of this
manual for more details.
CAUTION Lifting the turntable assembly using a forklift or other
lifting machinery should be performed by qualified personnel.
3. Using a forklift or other appropriate lifting device, place the
turntable bottom or bearing support section into position. If the
turntable is to be installed in a pit, center and level the
assembly.
CAUTION Ensure power is off and secured before proceeding
further.
4. The drawings at the back of this manual illustrate the
placement of floor plates and leveling screws to anchor and
level the turntable. Anchor the turntable through the attachment
holes provided using the concrete expansion bolts provided.
After installing the floor plates and leveling screws, level the
entire turntable by adjusting all the leveling screws between
and under the casters, and in the center section of the turntable.
5. Tighten all lock-nuts accompanying the leveling screws to lock
the height of the turntable into place.
