Identifying the Parts and Controls
Left-speaker operation panel/remote commander
I2[3] [4l
|5] [6] (71 ID
fr
For details, refer to the page numberCs) indicated in
parentheses.
[H
POWER
switch
[H Remote sensor
m AC STANDBY indicator
This indicator lights up when the system is connected to
an AC outlet and the system is in STANDBY mode.
S DOLBY PRO LOGIC ON/OFF button
DOLBY PRO LOGIC MODE button (pages 11 and 14)
m SURROUND button (page 11)
O
Display
[3 SUPER WOOFER ON/OFF button
SUPER WOOFER MODE button (page 11)
d] STD (standard) LEVEL button (page 13)
f9l DISPLAY button (page 11)
03
MUTING button (page 11)
01
INPUT (1 /2) button(s) (page 10)
03
TEST TONE
button (pages
12
and
13)
03
CENTER LEVEL +/-
buttons (pages
12
and
13)
03
DELAY TIME
button (page
13)
03
REAR LEVEL +/- buttons (pages 12 and 13)
03
S.WOOFER +/-buttons (page 12)
03
BASS +/- buttons (page 12)
03
TRE (treble) +/-buttons (page 12)
M
BALANCE L/R buttons (page 13)
MASTER VOL (VOLUME) +/- button(s) (pages 11
and 12)
