AVAILABLE ACCESSORIES
STRFGWX(I)
RF Gateway
PW(I)-1215
12 Volt Power Pack
1700C-BTNB
Set of 10 Black Button Caps
with Engraving
1700C-BTNS
Set of 10 Silver Button Caps
with Engraving
ST-PK
Programming Cable Kit
SMARTOUCH TM TOUCHPANELS
STX-1700CW
SmarTouch TM 2-Way Wireless Touchpanel with Wall Mount (continued)
SmarTouch TM Wall Mount Wireless Touchpanels
www.crestron.com | 800.237.2041 | 201.767.3400
© 2007 Specifications subject to change without notice
Battery
Model/Type: ST-BTPN battery pack, NiMH, 4.8 Volt, 4100 mAh
Usage per Charge: ~3 hours continuous use at full brightness,
20 hours in standby
Charging Time: 2.7 to 6 hours (depending upon use
while charging)
Power Requirements
Touchpanel: 18 Watts (1.5 Amps) @ 12 Volts DC
(PW-1215 power supply sold separately)
Docking Assembly (DA-1700CW included):
34 Watts Cresnet Power Usage (1.42 Amps @ 24 Volts DC)
Environmental
Temperature: 50° to 113°F (10° to 45°C)
Humidity: 10% to 90% RH (non-condensing)
Enclosure
Construction: High impact black/silver injection-molded case with
metal docking plate
Dimensions
Height: 3.85 in (9.78 cm)
Width: 8.75 in (22.23 cm)
Depth: 5.51 in (14.00 cm)
Weight
1.85 lbs (0.84 kg) – not including battery or docking assembly
INCLUDED ACCESSORIES
(See individual product specifications for complete information)
DA-1700CW
Docking Assembly
BB-1700CW
Back Box
ST-BTPN
Battery Pack
1700C-BTNB-BEZELS-BLANK
Button and Bezel Kit (engraving sold separately)
SPECIFICATIONS
Touchscreen Display
Display Type: TFT Active matrix color LCD
Size: 5.7 inch (14.5 cm) diagonal
Aspect Ratio: 4:3 QVGA
Resolution: 320 x 240 pixels
Color Depth: 16-bit, 64k colors
Illumination: Backlit fluorescent
Viewing Angle: ±65° horizontal, +65°/-40° vertical
Touchscreen: Resistive membrane
Buttons
(10) Replaceable engravable buttons, programmable
Requires installation of button bezel kit (included)
Wireless
RF Transceiver: 418 MHz 2-way RF
Range: 3 to 50 feet min/max indoor, 150 feet outdoor
STRFGWX RF Gateway required
(maximum 15 touchpanels per gateway)
Processor
CPU: 32-bit Freescale ColdFire ® Microprocessor
Memory
DRAM: 8 MB
Flash: 4 MB
Maximum Project Size: 3 MB
Graphic Engine
Isys engine, 16-bit non-palette graphics; 65,536 colors; Synapse
image rendering algorithm; multi-mode objects; animation
Audio
Built-in transducer for “key click” sound
Connectors
Power: (1)2.5mm barrel DC power jack
12 Volt DC power input (PW-1215 power supply sold separately)
Cresnet Upload: (1) 3.5 mm mini TRS phone jack
Connects to Cresnet control network while uploading only
