ClearOne comm CHAT 170 - Manual (Page 2)

Connections
USB connector
Version 2.0 compatible
Type: Mini B Female
Controls
Volume up
Volume down
Microphone mute
operating System Support
Windows XP
Windows Vista
Audio
Speaker
Bandwidth: 150Hz-15kHz
Max output level: 86dBSPL @ 1 foot
Microphone
Bandwidth: 50Hz-8kHz
Processing
Full-duplex
Acoustic echo cancellation
Noise cancellation
Automatic level controls
Power
USB-powered
5 VDC @ 500mA maximum
environmental
Operating temperature: 5-40 degrees C
(41-104 degrees F)
Storage temperature: 0-70 degrees C
(32-158 degrees F)
Mechanical
CHAT 170 dimensions (WxDxH): 7.4” x 7.4” x
1.8” (18.8cm x 18.8cm x 4.6cm)
Weight: 1.17 lbs (.53kg)
Compliance
RoHS
FCC Class A Part 15
ICES-003
EU compliance
Part number
910-156-250 CHAT 170
connects to PCs & laptops >
CHAT 170 DATA SHeeT <
> Components
> Specifications
> CleArone loCATionS
Headquarters:
Salt Lake City, UT USA
5225 Wiley Post Way
Suite 500
Salt Lake City, UT 84116
Tel: 801-975-7200
Toll Free: 800-945-7730
Fax: 801-977-0087
[email protected]
Latin America
Tel: 801-974-3621
[email protected]
EMEA
Tel: 44 (0) 1189 036 053
[email protected]
APAC
Tel: 801-303-3388
[email protected]
© 2009 ClearOne. All rights reserved. Information in this document is subject to change without notice. Microsoft and Office Communicator are trademarks of the Microsoft group of companies in the United
States and/or other countries.
ClearOne Document: 802-156-250-DS Revision 1.53 March 2009.
CHAT 170
USB 2.0
Connection Cable
Quick Start Guide
Part# 830-156-200 Part# 800-156-202
ready to use out of the box
All the components you need to quickly get up and running, including
USB cable and quick start guide.
