Great Plains Manufacturing, Inc. Table of Contents Index Adjustments 63
2014-06-17 Table of Contents Index 401-923M
Frame-Mounted Vantage I Coulters
Refer to Figure 65
At the shaft
, adjust the coulter depth for a running
depth of 4 to 4
1 ⁄
2
inch (10.2 to 11.4 cm) below ground
level if off row, if on row as a no-till coulter operate at
planting depth only
. Refer to the Vantage I manual
(204-376M) for further adjustments.
Do not adjust the spring tension. It is factory pre-set.
Vantage I Liquid Fertilizer Applicator
Refer to Figure 66
At the back plate
, adjust the tine height for a running
depth of 1 inch (2.5 cm) below ground level . Refer
to the Vantage I manual (204-376M) for further
adjustments.
Figure 65
Frame-Mount Coulter
25392
1
4
3
2
1
2
3
4
Figure 66
Vantage I Applicator
22951
5
3
6
5
6 3
