Safeguards and Precautions
1. Read and follow all instructions in this manual carefully, and retain
this manual for future reference.
2. Do not use this instrument in any manner inconsistent with these
operating instructions or under any conditions that exceed the
environmental specifications stated.
3. Certain strobe frequencies can trigger epileptic seizures in those
prone to that type of attack.
4. Users should not stare directly at the light source.
5. Prolonged exposure to the light can cause headaches in some
people.
6. Objects viewed with this product may appear to be stationary when
in fact they are moving at high speeds. Always keep a safe distance
from moving machinery and do no touch the target.
7. There are no user serviceable parts in this instrument. Refer service
to a qualified technician.
8. Do not allow liquids or metallic objects to enter the ventilation holes
on the stroboscope as this may cause permanent damage and void
the warranty.
9. Do not allow cables extending from unit to come into contact with
rotating machinery, as serious damage to the equipment, or severe
personal injury or death may occur as a result.
10. This instrument may not be safe for use in certain hazardous
environments, and serious personal injury or death could occur as
a result of improper use. Please refer to your facility’s safety program
for proper precautions.
11
Display LCD display with 6 numeric 0.506 inch [12.85
mm] high digits and 5 alphanumeric 0.282 inch
[7.17 mm] high digits
Indicators Battery level
Knob Adjustment Digital Rotary switch with 36 detents per
revolution; velocity sensitive
Input Power Battery powered: Internal Rechargeable Batteries
6 Vdc
Light Output Average: 3000 Lumens @6000 FPM 12" from lens
Flash Duration Adjustable 0.5 to 3000 microseconds or 0.2 to 14
degrees of rotation (auto adjust with flash rate)
Run Time 12 hours typical at 6000 FPM, and 2.8° pulse width
with fully charged batteries
Charge Time 4-5 hours typical with supplied recharger
Weight 1.875 lbs [0.8505 kg] including batteries
Safety This product is designed to be safe for indoor use
under the following conditions (per IEC61010-1).
Operating Temperature 32-104 ºF [0-40 °C]
Humidity Maximum relative humidity 80% for temperature
up to 88 °F [31 °C] decreasing linearly to 50%
relative humidity at 104 °F [40 °C]
Specifications subject to change without notice.
This product is CE certified and ROHS compatible.
Manufactured in an ISO9001 facility.
For troubleshooting information and technical support visit
www.monarchinstrument.com.
