INSTALLATION INSTRUCTIONS
Socket
STEP 4
:
a Place the Shade over the Socket as shown. Using the
Socket Collar Tool, thread the Socket Collar onto the
Socket to secure the Shade. Hand tighten until snug.
.
STEP 5
:
a Adjust the Shade to your desired location by adjusting the
Swivel.
.
STEP 6:
a
Install correct bulbs referring to fixture markings and or labels for maximum wattage
Your installation is completed now. Restore electricity. Retain this sheet for future reference.
.
/
.
Shade
Socket Collar
Socket Collar Tool
STYLE NUMBER DH1404AN, DH1404PN
:
Swivel
