REV. B
SPECIFICATIONS
KU36
Acoustics
Power handling
2 X 80 W
(AES)
Impedance
2 X 4W
Operating frequency range
45 Hz - 300 KHz.
SPL 1W / 1mt
89 dB
Maximum SPL
115 dB continuous - 121 dB peak
Transducers
Full range
1 X 6” Neodymium magnet with 1.5” voice coil
+ 2 X 6” passive transducer
Audio Input
Connectors
4-pin Phoenix
Wiring
Pin1=Ch 1+, Pin2=Ch 1-, Pin3=Ch 2+, Pin4=Ch 2-
Recommended Amplifiers
KA1-1, KA7-7, KA10-10
Physical
Dimensions
50.7 x 17.5 x 10.5 cm (19.96” x 6.89” x 4.13”)
Weight
6.8 Kg (15 lbs)
New materials and design are introduced into existing
products without previous notice. Present systems may differ
in some respects from those presented in this brochure.
