Models, Pressure – temperature – Watts LFFS-CFC-S User Manual
Page 2

MODel
SIze
length
BraID MaterIal
WeIght
in.
in.
mm
lbs
kgs
LFFS-CFC-S-CC
3
⁄
8
x
3
⁄
8
12
305
Stainless Steel
0.25
0.11
LFFS-CFC-S-CC
3
⁄
8
x
3
⁄
8
16
406
Stainless Steel
0.28
0.12
LFFS-CFC-S-CC
3
⁄
8
x
3
⁄
8
20
508
Stainless Steel
0.32
0.15
LFFS-CFC-S-CF
1
⁄
2
x
1
⁄
2
12
305
Stainless Steel
0.28
0.12
LFFS-CFC-S-CF
1
⁄
2
x
1
⁄
2
16
406
Stainless Steel
0.31
0.14
LFFS-CFC-S-CF
1
⁄
2
x
1
⁄
2
20
508
Stainless Steel
0.35
0.16
LFFS-CFC-S-CF
3
⁄
8
x
1
⁄
2
12
305
Stainless Steel
0.27
0.12
LFFS-CFC-S-CF
3
⁄
8
x
1
⁄
2
16
406
Stainless Steel
0.31
0.14
LFFS-CFC-S-CF
3
⁄
8
x
1
⁄
2
20
508
Stainless Steel
0.34
0.15
LFFS-CFC-S-CF
7
⁄
16
x
1
⁄
2
12
305
Stainless Steel
0.26
0.12
LFFS-CFC-S-CF
7
⁄
16
x
1
⁄
2
16
406
Stainless Steel
0.30
0.14
LFFS-CFC-S-CF
7
⁄
16
x
1
⁄
2
20
508
Stainless Steel
0.34
0.15
LFFS-CFC-S-FF
1
⁄
2
x
1
⁄
2
12
305
Stainless Steel
0.32
0.14
LFFS-CFC-S-FF
1
⁄
2
x
1
⁄
2
16
406
Stainless Steel
0.36
0.16
LFFS-CFC-S-FF
1
⁄
2
x
1
⁄
2
20
508
Stainless Steel
0.39
0.18
LFFS-CFC-S-TF
1
⁄
2
x
1
⁄
2
12
305
Stainless Steel
0.28
0.13
LFFS-CFC-S-TF
1
⁄
2
x
1
⁄
2
16
406
Stainless Steel
0.31
0.14
LFFS-CFC-S-TF
1
⁄
2
x
1
⁄
2
20
508
Stainless Steel
0.35
0.16
LFFS-CFC-S-TF
3
⁄
8
x
1
⁄
2
12
305
Stainless Steel
0.27
0.12
LFFS-CFC-S-TF
3
⁄
8
x
1
⁄
2
16
406
Stainless Steel
0.31
0.14
LFFS-CFC-S-TF
3
⁄
8
x
1
⁄
2
20
508
Stainless Steel
0.34
0.15
LFFS-CFC-S-CO
3
⁄
8
x
3
⁄
8
12
305
Stainless Steel
0.27
0.12
LFFS-CFC-S-CO
3
⁄
8
x
3
⁄
8
20
508
Stainless Steel
0.34
0.15
Models
LF
FS-CFC-S-CC – Both ends of the flexible connector are
supplied with plated solid brass nut
compression end fittings for connection to
supply stop valves and faucets.
LF
FS-CFC-S-CF – One end of the flexible connector is sup
plied with a plated, solid brass compres-
sion end fitting for connection to a supply
stop valve. The other end is supplied with a
plated, solid brass female iron pipe thread
fitting.
LF
FS-CFC-S-FF – Both ends of the flexible connector are
supplied with a plated, solid brass female
iron pipe thread fittings.
LF
FS-CFC-S-TF – One end of the flexible connector is sup-
plied with a plated, solid brass female iron
pipe thread fitting. The other end with a
plated, solid brass fine thread female iron
pipe fitting.
LFFS-CFC-S-CO – One end of the flexible connector is sup-
plied with a plated solid brass compres-
sion end fitting for connection to a supply
stop valve. The other end is supplied with
a plated, solid brass OD compression end
fitting.
Pressure – Temperature
Minimum bend radius: 2.5 inches
Maximum Continuous Pressure: 125 psi/8.6 bar
Maximum intermittent impulse pressure: 180 psi/12.4 bar
Maximum Continuous Temperature: 160°F/71°C
Maximum intermittent exposure: 180°F/82°C
For use with water in accessible locations only
ES-LFFS-CFC-S 1313
