The Puck™ Fab5 User Manual Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
DMX Quick Reference (12-Channel Mode)
Channel What It Does
1
Dimmer
2 Strobe (0-15 off, 16-255 strobe slow <-> fast)
3 Red Intensity
4 Green Intensity
5 Blue Intensity
6 Amber Intensity
7 White Intensity
8 Color Snap
9 Snap Speed (0-15 off, 16-255 Snap Slow <--> Fast)
10 Color Fade
11 Fade Speed (0-15 off, 16-255 Snap Slow <--> Fast)
12 Sound Active (0-127 off, 128-255 Sound Active)
2. MEET ThE PUCk™ FAB5 FLAT LED PAR FIxTURE
MAIn FEATURES
• Light Source: 7* 15-watt, 5-in-1 RGBWA All-In-One LED’s
• Variable electronic strobe and dimmer
• Built-in automated programs via DMX and master/slave
• Built-in sound active programs
• Full RGBAW color mixing in standalone and master/slave
• Color Preset (3-Channel), RGBAW (5-Channel) and extended (12-Channel) DMX
• Able to directly power the wiCICLE® wireless system via DMX
ADDITIONAL FEATURES
• Lightweight and Compact (It kept its New Years’ resolution!)
• 4-Button LED control panel for easy programming
• Dual bracket for flexibility in mounting
• Power outlet for fixture linking (up to 50 fixtures)
• Running hours display
• Two-piece mounting yoke allows flexibility in positioning
Optical:
• Beam Angle: 25°, Field Angle: 29°
• Light Source: 7* 15-watt, 5-in-1 RGBWA All-In-One LED’s
• Flicker-free constant-current LED driver
