Bendix Commercial Vehicle Systems TU-FLO 550 COMPRESSOR 6/08 User Manual
Page 10
10
ITEM QTY DESCRIPTION
ITEM QTY
DESCRIPTION
ITEM QTY DESCRIPTION
1
6
Cylinder Head Cap Screws
16
2
Discharge Valve Spring
31
2
Thrust Washer
2
4
Unloader Plate Cap Screws
17
2
Discharge Valve
32
2
Sleeve (or Ball) Bearing
3
4
Unloader Plate Lock Washers
18
2
Discharge Valve Stop
33
1
End Cover Seal
4
1
Unloader Plate
19
1
Cylinder Head Gasket
34
1
End Cover
5
1
Unloader Plate Gasket
20
1
Base Gasket
35
4
End Cover Cap Screws
6
2
O-ring
21
1
Base Plate
36
2
Wrist Pin Bushing
7
2
Unloader
22
6
Base Plate Cap Screws
37
2
Connecting Rod
8
2
Spring
23
6
Standard Piston Rings
38
2
Conn. Rod Inserts (Sets)
9
2
Unloader Bushing
24
8
Oil Ring
39
2
Connecting Rod Caps
10
2
Gasket
25
4
Expander Ring
40
4
Connecting Rod Bolts
11
2
Inlet Valve Seat
26
2
Piston
41
1
Ball Bearing
12
2
Inlet Valve
27
2
Wrist Pin
42
1
Retaining Ring
13
2
Inlet Valve Spring
28
4
Wrist Pin Button
43
1
Seal
14
2
Inlet Valve Stop
29
1
Crankshaft
44
1
Cotter Pin
15
2
Discharge Valve Stop
30
1
Crankshaft Key
45
1
Locknut
2
4
5
6
7
8
9
BALL BEARING
(MACK EXTENDED
FLANGE)
NAMEPLATE
3
26
23
23
24
25
24
28
27
35
37
33
32
36
11
12
13
14
10
29
38
39
40
1
CYLINDER
HEAD
15
16
17
18
19
32
22
21
20
31
CRANKCASE
19
42
44
FLANGE
MOUNT
BASE
MOUNT
32
32
20
CRANKCASE
30
34
24
24
23
25
