2
Using WebPak
3000 ControlNet
Communications Option Board I/O With a ControlLogix
Processor
You can also contact the Rockwell Automation technical support division for the product related to your
question:
Required Equipment and Software Versions
Table 2 lists the equipment and software versions required to set up communications between a ControlLogix
processor and a WebPak 3000 drive.
If the firmware in your ControlLogix equipment does not meet the above requirements, contact the Control and
Information Group technical support division (1-440-646-6800) to obtain a copy of the appropriate
ControlFlash upgrade kit.
Configuring an I/O Connection
Before configuring an I/O connection, you must:
•
Configure the WebPak 3000 drive network parameters (refer to chapter 3 in D2-3425-2), set the network
drop number appropriately, and set the control source to network.
•
Verify that you have used RSNetWorx for ControlNet to configure the network containing the ControlLogix
chassis and WebPak 3000 drive.
Use the following procedure to configure an I/O connection:
Step 1. After opening the RSLogix 5000 software, verify that you are off-line with the ControlLogix processor.
You can configure an I/O connection when starting a new project or after opening an existing project,
but I/O can only be configured off-line.
Division
Telephone
E-mail/Web Address
Rockwell Software
(RSLinx, RSNetWorx for ControlNet,
RSLogix 5000 software)
1-440-646-7800
http://www.software.rockwell.com/support/
Control and Information Group
(ControlLogix system, ControlNet
network)
1-440-646-6800
Table 2 – Required Equipment and Software Versions
Equipment Description
Part Number
Version
•
RSLinx software
9355-WABENE
Version 2.20 or later
•
RSNetWorx for ControlNet software
9357-CNETL3
Version 2.25 or later
•
RSLogix 5000 software
9324-RDL300ENE
Version 6.00 or later
•
ControlLogix processor
1756-L1
Firmware version 6.20
or later
•
ControlLogix ControlNet bridge (1756-CNB or
1756-CNBR)
1756-CNB or 1756-CNBR
Series A, V1.19
Series B, V2.27 or later
Series D, V5.22
•
FlexPak 3000/WebPak 3000 ControlNet Network
Communications board
915FK2101
Version 2.2 or later
