Navigating the Software
Publication 2706-6.2
Use the following keys to navigate through the Offline Programming
Software menus. These keys have the same effect wherever they are
used in the software. Individual screens may use additional
keystroke commands. These additional commands are described
immediately below the sample screens that appear throughout this
manual.
Help. Pressing F1 when Help is open will open the Menu Key
Control help screen
Toggle Help screen between partial and full screen view.
Return to the previous menu.
↵
Select highlighted menu item.
↑
Highlight previous menu item.
↓
Highlight next menu item
→
Move the cursor to the right
←
Move the cursor to the left
Highlight first menu item.
Highlight last menu item.
You can also select most menu items by typing their initial letter.
For example, to exit the program you can type [E][Y]. [E] is the
initial letter in the Exit Main menu item, and [Y] is the initial letter
of the Yes Exit menu item.
Menu Control Keys
Shortcut Keys
