Wood’s Powr-Grip CF1IFO - Manual (Page 2)

Rev 4.0/3-09 APPENDIX • OPTION CF1IFO #35170: 2
Installation (see figure)
1) Support the pad frame {1} as described in the preceding Removal directions, and align the 4
mounting holes {4} in the rotation housing {3} with those in the innermost tubes of the pad
frame: First rotate the rotation housing so that its mounting holes will match those in the pad
frame. Then tilt the rotation housing to match the orientation of the pad frame. Finally, use the
hoist to move the lift bar assembly {5} into position so that the mounting holes align.
2) Install the 4 mounting bolts {6} one by one in the mounting holes: First apply a removable
thread-locking adhesive to the threads of a mounting bolt. Then use a hex key to tighten the
bolt until its shoulder seats securely against the rotation housing. Repeat for all bolts.
Note: Make sure the shoulder of each mounting bolt is contacting the rotation housing,
not the
inside wall of the pad frame tube. When a bolt is installed correctly, the gap between the bolt
head and the pad frame should measure less than 1/8" [3 mm].
3) Attach the vacuum hose to the 2 barbs of the rotation fittings assembly {2}: Use a small
amount of glycerin on the inside of the hose to ease installation. Push the free end of each hose
over the corresponding barb. Make certain that both hoses are connected securely.
4) Perform Operational Tests of the pad frame and vacuum system (see I
NSPECTIONS AND
T
ESTING
to follow).
I
NSPECTIONS AND
T
ESTING
When performing inspections and tests of the lifter as directed in the MAINTENANCE section of
the main instructions, be sure to include the currently installed pad frame whenever applicable.
R
EPLACEMENT
P
ARTS
Stock No. Description
28302 Loctite Threadlocker - Removable
SERVICE ONLY WITH IDENTICAL REPLACEMENT PARTS
SUPPLIED BY OR APPROVED BY WOOD'S POWR-GRIP CO., INC.
