PAGE 12 — DCA125SSIU 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #3 (01/13/11)
Table 1. Generator Specifi cations
Model DCA-125SSIU
Type
Revolving fi eld, self ventilated,
open protected type synchronous generator
Armature Connection Star with Neutral Zigzag
Phase 3 Single
Standby Output 110 KW (137.5 kVA) 79 KW
Prime Output 100 KW (125 kVA) 72 KW
3Ø Voltage (L-L/L-N)
Voltage Selector Switch at 3Ø 240/139
208Y/120, 220Y/127,
240Y/139
N/A
3Ø Voltage (L-L/L-N)
Voltage Selector Switch at 3Ø 480/277
416Y/240, 440Y/254,
480Y/277
N/A
1Ø Voltage (L-L/L-N)
Voltage Selector Switch at 1Ø 240/120
N/A 240/120
Power Factor 0.8 1.0
Frequency 60 Hz
Speed 1800 rpm
Aux. AC Power Single Phase, 60 Hz
Aux. Voltage/Output 4.8 Kw (2.4 kW x 2)
Dry Weight 4,609 lbs. (2,090 kg.)
Wet Weight 5,182 lbs. (2,350 kg.)
Table 2. Engine Specifi cations
Model ISUZU 4HK1X
Type
4 cycle, water-cooled, direct injection, turbo-charged
with charged air-cooled
No. of Cylinders 4 cylinders
Bore x Stroke 4.53 in. x 4.92 in. (115 mm x 125 mm)
Displacement 317 cu. in. (5,193 cc)
Rated Output 152 HP at 1800 rpm
Starting Electric
Coolant Capacity 5.30 gal. (20.2 liters)
Lube Oil Capacity 5.99 gal. (22.7 liters)
Fuel Type #2 Diesel Fuel
Fuel Tank Capacity 63 gal. (240 liters)
Fuel Consumption
7.3 gal. (27.6 L)/hr at full load 5.7 gal. (21.7 L)/hr at 3/4 load
4.1 gal. (15.4 L)/hr at 1/2 load 2.5 gal. (9.5 L)/hr at 1/4 load
Battery 12V-128 Ah x 1
