MQ MP2 SERIES SAW — PARTS MANUAL — REV. #1 (03/26/10) — PAGE 51
FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 16854ZH8000 RUBBER, SUPPORTER (107MM) 1
2 16955ZE1000 JOINT, FUEL TANK 1
5 17510ZE2010ZD TANK, FUEL *NH1* (BLACK) 1
7 17620ZH7023 CAP, FUEL FILLER .......................................... 1..............INCLUDES ITEMS W/ *
12 91353671003 O-RING (13.5X1.5) (ARAI) 1
14 9405008000 NUT, FLANGE (8MM) 2
15 950014500360M BULK HOSE, FUEL (4.5X3000) (4.5X222) 1
16 9500202080 CLIP, TUBE (B8) 2
17 957010802500 BOLT, FLANGE (8X25) 2
22 17631ZH7003 GASKET, FUEL FILLER CAP 1
GX270QWH2 ENGINE — FUEL TANK ASSY.
