JWN-SERIES— SPECIFICATIONS (TROWEL)
2.
The vibration level indicated is the maximum RMS (Root
Mean Square) value obtained at the handle grip while
operating the ride-on trowel on curing concrete in a
manner most often experienced in “
normal
”
circumstances. Values were obtained from all three axes
of motion. The values shown represent the maximum RMS
value from these measurements.
Figure 1. JWN-Series Dimensions Specifications
C = 46.75 inches
B =39 inches
A = 77 inches
NOTE:
1.
Sound pressure is "A" weighted . Measured at the operators
ear position while the ride-on trowel is operating at full
throttle on concrete in a manner most often experienced in
“
normal
” circumstances. Sound pressure may vary
depending upon the condition of the concrete. Hearing
protection is always recommended.
