3 Mechanical installation
Important notes
EDK82ZM113−002 DE/EN/FR 2.1
36
l
H1_MechINS−Montageschritte_E82ZM113−002
3 Mechanical installation
Important notes
ƒ The mounting location must always comply with the operating conditions specified
in the technical data ( ^ 31). Take additional measures if necessary.
ƒ The mounting plate of the control cabinet must have the following properties:
– electrically conductive
– free of lacquer
ƒ A free air circulation must be ensured for dissipating the heat.
Mounting steps
How to mount the filter:
1. Select a suitable mounting location in the control cabinet.
2. Depending on the design, mount the filter using two or four screws and washers.
